Exploded view — Meter Combination - Cruscotto

Products

1 Instrument cluster Available 1D003493

•

  Instrument Cluster Piaggio Group · 1D003493 Available · Shipped in 3–5 working days

  € 434,20

  Add to cart

2 Instrument support Backorder 1B008832

•

  Bracket for cockpit instruments Piaggio Group · 1B008832 Backorder · Shipped in 2–4 weeks

  € 23,78

  Add to cart

3 Screw Available CM179301

• • Country: Indonesia
  • Country: Japan


  Screw M6x16 Piaggio Group · CM179301 · Quantity needed: 3 Available · Shipped in 3–5 working days

  € 1,48

  Add to cart

4 Screw (M5x16) Available 2928896

•

  Screw M5x16 Piaggio Group · 2928896 · Quantity needed: 4 Available · Shipped in 3–5 working days

  € 0,99

  Add to cart

5 Flat washer Backorder 1B009244

•

  Washer Piaggio Group · 1B009244 · Quantity needed: 4 Backorder · Shipped in 2–4 weeks

  € 1,78

  Add to cart

6 Cylindrical cable grommet Backorder 1B009243

•

  Cable Guide Piaggio Group · 1B009243 · Quantity needed: 4 Backorder · Shipped in 2–4 weeks

  € 0,99

  Add to cart

7 Bushing Backorder 1B009242

•

  Sleeve Piaggio Group · 1B009242 · Quantity needed: 4 Backorder · Shipped in 2–4 weeks

  € 2,65

  Add to cart
