Exploded view — Central Cover - Footrests

‹ Back to model

Piaggio Zip 50 4T 2021

Piaggio Zip 50 4T 2021

Central Cover - Footrests

Products

1 Footrest Available 1B0050210000C

Footwell Cover Piaggio Group · 1B0050210000C Available

€ 97,72

2 Screw (M6x16) Available 575249

Screw M6 Piaggio Group · 575249 · Quantity needed: 4 Available

€ 0,99

3 Screw Available 259349

Screw 4,2x13 mm Piaggio Group · 259349 · Quantity needed: 2 Available

€ 0,99

6 Clip nuts (M6) Available 254485

Sheet nut Piaggio Group · 254485 · Quantity needed: 4 Available

€ 2,04

7 Spark plug access cover Available 575404000C

Inspection Cover, black, dyed Piaggio Group · 575404000C Available

€ 37,56

11 Helmet compartment cover Available 575405000C

Fairing, black, dyed Piaggio Group · 575405000C Available

€ 49,31

13 Clip nuts Available CM017410

Sheet nut Piaggio Group · CM017410 · Quantity needed: 2 Available

€ 0,99
