Exploded view — Handlebars Coverages

‹ Back to model

Piaggio Zip 50 4T 2021

Piaggio Zip 50 4T 2021

Handlebars Coverages

Products

1 Front handlebar cover Available 1B000995

Handlebar Fairing, front, primed Piaggio Group · 1B000995 Available

€ 38,48

2 Screw Available 297498

Sheet Metal Screw Piaggio Group · 297498 Available

€ 0,99

3 Screw Available 267958

Sheet Metal Screw length: 20mm Piaggio Group · 267958 · Quantity needed: 3 Available

€ 0,99

4 Rear handlebars cover Available 581323000C

Handlebar Fairing, rear, black, dyed Piaggio Group · 581323000C Available

€ 35,14

5 Screw Available 296458

Sheet Metal Screw length: 35mm Piaggio Group · 296458 · Quantity needed: 2 Available

€ 0,99

6 Screw Available 008457

Thread Screw 4,2x19 mm Piaggio Group · 008457 Available

€ 1,59

7 Clip nuts Available CM017409

Sheet nut Piaggio Group · CM017409 Available

€ 1,48

8 Brake pump cover Available 679120

Cover Piaggio Group · 679120 Available

€ 15,95
Cover, black, dyed Piaggio Group · 582419000C Available

€ 16,65
