Exploded view — Air Filter
‹ Back to model
Derbi Atlantis 50 2T Two Chic 2005
Products
1 Secondary air box
-
8318595 Secondary air boxNo longer available
2 Filter sas Available
-
- Carburettor version (C364M)
Air Filter Insert Piaggio Group · 486942 Available · Shipped in 3–5 working days€ 5,53
3 Gasket Available
-
- Carburettor version (C364M)
Gasket Piaggio Group · 486943 Available · Shipped in 3–5 working days€ 10,30
4 Diaphragm Available
-
- Carburettor version (C364M)
Reed valve for secondary air system Piaggio Group · 82758R Available · Shipped in 3–5 working days€ 30,08
5 Cover sas Available
-
- Carburettor version (C364M)
Lid Piaggio Group · 827209 Available · Shipped in 3–5 working days€ 23,70
6 Screw Available
-
- Carburettor version (C364M)
Thread Screw Piaggio Group · 478533 Available · Shipped in 3–5 working days€ 1,26
7 Air hose
-
00G04204721 Air hoseNo longer available
8 Clamp Available
-
- Carburettor version (C364M)
Hose Clamp Piaggio Group · CM001905 Available · Shipped in 3–5 working days€ 1,82
9 Clamp Backorder
-
- Year of manufacture: 2011
- Country: Austria
- Country: Denmark
Hose clamp Piaggio Group · 00H03801751 Backorder · Shipped in 2–4 weeks€ 8,22
10 SLEEVE Backorder
-
Hose Piaggio Group · 00G04200731 Backorder · Shipped in 2–4 weeks€ 13,03
11 Screw Available
-
- Carburettor version (C364M)
- Injection version (C361M)
Screw M5x25 Piaggio Group · 015597 Available · Shipped in 3–5 working days€ 1,75
12 Intake pipe sas Available
-
- Carburettor version (C364M)
Inlet pipe Piaggio Group · 827208 Available · Shipped in 3–5 working days€ 7,14
13 Fairlead Available
-
Cable Guide Piaggio Group · 827794 Available · Shipped in 3–5 working days€ 2,48
14 Air filter box Available
-
Air Filter complete Piaggio Group · 1A017938 Available · Shipped in 3–5 working days€ 178,67
15 Seal air filter box Available
-
Gasket Piaggio Group · 487718 Available · Shipped in 3–5 working days€ 7,65
16 Air filter Available
-
Air Filter Insert Premium Piaggio Group · 1A0122830P Available · Shipped in 3–5 working days€ 8,37
17 Screw Available
-
Thread Screw Piaggio Group · 258146 Available · Shipped in 3–5 working days€ 0,99
18 Spacer Available
-
Sleeve Piaggio Group · 830056 Available · Shipped in 3–5 working days€ 1,48
19 Intake hose Available
-
- Switzerland version E3
- Year of manufacture: 2011
- Country: Switzerland
Inlet pipe Piaggio Group · 829715 Available · Shipped in 3–5 working days€ 17,29
20 Air bellow Available
-
Sleeve Piaggio Group · 487592 Available · Shipped in 3–5 working days€ 19,75
