Exploded view — Drive Shaft

Products

1 Crankshaft 00Q20001008 No longer available

• 00Q20001008 Crankshaft
  No longer available

2 PISTON 00Q20001009 No longer available

• 00Q20001009 PISTON
  No longer available

3 Piston ring set 00Q20001010 No longer available

• 00Q20001010 Piston ring set
  No longer available

4 GEAR, TIMING DRIVE (22T) 00Q20001039 No longer available

• 00Q20001039 GEAR, TIMING DRIVE (22T)
  No longer available

5 PLUG ASS'Y, BEARING PUSH 00Q20001052 No longer available

• 00Q20001052 PLUG ASS'Y, BEARING PUSH
  No longer available

6 Oil seal 00Q20001142 No longer available

• 00Q20001142 Oil seal
  No longer available

7 O-Ring 00Q20001145 No longer available

• 00Q20001145 O-Ring
  No longer available

8 Bearing 00Q20001155 No longer available

• 00Q20001155 Bearing
  No longer available

9 Bearing 00Q20001154 No longer available

• 00Q20001154 Bearing
  No longer available

10 Piston pin 00Q20001158 No longer available

• 00Q20001158 Piston pin
  No longer available

11 KEY, WOODRUFF 25*14*4 00Q20001161 No longer available

• 00Q20001161 KEY, WOODRUFF 25*14*4
  No longer available

12 Screw 00Q25001500 No longer available

• 00Q25001500 Screw
  No longer available

13 CIRCLIP, PISTON PIN 00Q25001526 No longer available

• 00Q25001526 CIRCLIP, PISTON PIN
  No longer available

14 WASHER, PLANE 6.2*14*1.5 00Q20001184 No longer available

• 00Q20001184 WASHER, PLANE 6.2*14*1.5
  No longer available
