Exploded view — Front Glove-box - Knee-guard Panel

Products

1 Front leg shield plate Available 675226000P

•

  Glove Box, black, dyed Piaggio Group · 675226000P Available

  € 214,88

  Add to cart

2 Top box weatherseal Available CM016804

•

  Gasket Piaggio Group · CM016804 Available

  € 11,27

  Add to cart

3 Square Available 252420

•

  Bracket Piaggio Group · 252420 Available

  € 4,94

  Add to cart

4 Door fixing bracket Available 257614

•

  Bracket Piaggio Group · 257614 · Quantity needed: 2 Available

  € 2,26

  Add to cart

5 Screw Available 297498

•

  Sheet Metal Screw Piaggio Group · 297498 · Quantity needed: 4 Available

  € 0,99

  Add to cart

6 Opening tab for glove compartment Available 295528

•

  Hooks Piaggio Group · 295528 Available

  € 13,78

  Add to cart

7 Spring Available 257617

•

  Spring Piaggio Group · 257617 Available

  € 1,80

  Add to cart

8 Clip nuts Available 573057

•

  Sheet nut Piaggio Group · 573057 Available

  € 6,80

  Add to cart

9 Glove compartment door 621210 No longer available

• 621210 Glove compartment door
  No longer available
•

  Glove Box Flap, black, dyed Piaggio Group · 656675000P Available

  € 77,60

  Add to cart

10 Bag holder hook Available 575819

•

  Hooks Piaggio Group · 575819 Available

  € 17,99

  Add to cart

11 Screw Available 259349

•

  Screw 4,2x13 mm Piaggio Group · 259349 · Quantity needed: 2 Available

  € 0,99

  Add to cart

12 Screw Available 259348

•

  Oval Head Screw Piaggio Group · 259348 Available

  € 1,08

  Add to cart

13 Clip nuts (M6) Available 254485

•

  Sheet nut Piaggio Group · 254485 Available

  € 2,04

  Add to cart
