Exploded view — Fork/steering Tube - Steering Bearing Unit

Products

1 Complete front fork Available 667080

•

  Fork Piaggio Group · 667080 Available

  € 337,46

  Add to cart

2 Sleeve Available 647594

•

  Protection piece Piaggio Group · 647594 · Quantity needed: 2 Available

  € 94,94

  Add to cart

3 Pad Available 601409

•

  Buffer Piaggio Group · 601409 · Quantity needed: 2 Available

  € 5,35

  Add to cart

4 Fork tube Right Backorder 601403

•

  Fork Leg right Piaggio Group · 601403 Backorder

  € 277,68

  Add to cart

5 Fork dust seal Available 601413

•

  Dust guard Piaggio Group · 601413 · Quantity needed: 2 Available

  € 11,39

  Add to cart

6 Fork tube Left Backorder 601404

•

  Fork Leg left Piaggio Group · 601404 Backorder

  € 277,68

  Add to cart

7 2 - Fork oil seal Available 601412

•

  Fork Seal 30x42x11 mm Piaggio Group · 601412 · Quantity needed: 2 Available

  € 26,18

  Add to cart

8 Main spring Available 601410

•

  Fork spring Piaggio Group · 601410 · Quantity needed: 2 Available

  € 13,12

  Add to cart

9 Sleeve Backorder 601417

•

  Steering Tube Piaggio Group · 601417 · Quantity needed: 2 Backorder

  € 51,07

  Add to cart

10 Steering bearing (UPPER) Available 65069345

•

  Steering bearing kit top Piaggio Group · 65069345 Available

  € 21,18

  Add to cart

11 Missing description 000000 No longer available

• 000000 Missing description
  No longer available

12 Steering bearing (LOWER) Available 65007545

•

  Steering bearing kit bottom Piaggio Group · 65007545 Available

  € 31,01

  Add to cart

14 Washer of the steering Available 0037514

•

  Washer Piaggio Group · 0037514 Available

  € 1,48

  Add to cart

15 Steering tube ring nut Available 0111094

•

  Threaded ring Piaggio Group · 0111094 Available

  € 13,31

  Add to cart
